| Ref | Part Number | Description | Retail | |
|---|
| 1 | EKMU0016 | | $ |
|
| 2 | ZCMU0015 | GASKET - CENTERCASE - CX50 VENOM | $ 14.33 |
|
| 3 | HCBC0665 | M6 X 65 SHCS ZINC | $ 1.54 |
|
| 4 | HCBC0604 | R/B HCBC0635 - M6 X 35 SHCS ZINC | $ 1.09 |
|
| 5 | ECMU0258 | CRANKSHAFT - CX50 - VENOM | $ 299.88 |
|
| 6 | ECMU0016 | BEARING - 50CC CRANKSHAFT & 65CC TRANS | $ 22.12 |
|
| 7 | ECMU0118 | SEAL - CRANKSHAFT - 50CC STD | $ 11.44 |
|
| 8 | ECMU0122 | DOWEL - HOLLOW - 8.4 x 14 x 7 - AISI 1215 | $ 2.2 |
|
| 9 | ECMU0999 | GEAR OUTPUT WIDE TOOTH 50 | $ 165.67 |
|
| 10 | ECMU0268 | GEAR - INPUT TRANSMISSION - CX50 VENOM | $ 133.4 |
|
| 11 | ECMU0001 | BEARING - TRANS. SEC. GEAR | $ 22.12 |
|
| 12 | ECKG0031 | BEARING 6001 NO SEALS | $ 9.88 |
|
| 14 | ECKGBR01 | BEARING OUTPUT- 50 & 65 | $ 29.91 |
|
| 15 | ECMU0236 | SEAL OUTPUT - CX50 VENOM | $ 10.99 |
|
| 16 | ECMU0237 | SNAP RING - OUTPUT BEARING - CX50 VENOM | $ 3.87 |
|
| 17 | ECKGSR03 | SNAP RING-OUTPUT- ext 20mm - FOR OUTPUT SHAFT | $ 2.54 |
|
| 18 | PCKG0015 | SPROCKET 15T | $ 18.78 |
|
| 19A | ECMU0176 | SHIM - SPROCKET - 0.2 THK 20/28 ID/OD | $ 3.32 |
|
| 19B | ECMU0177 | SHIM - SPROCKET - 0.3 THK 20/28 ID/OD | $ 3.32 |
|
| 19C | ECMU0178 | SHIM - SPROCKET - 0.5 THK 20/28 ID/OD | $ 3.32 |
|
| 20 | ECMU0233 | R/B ECMU0233P - VENT HOSE NIPPLE (LARGE) | $ 9.88 |
|
| 21 | ECMU0557 | HOSE CRANKCASE VENT 2010 - CURRENT 50cc | $ 8.88 |
|
| 22 | ECMU0272BLK | PLUG - OIL FILL - OIL DRAIN - COOLANT - VENOM - BLACK | $ 12.11 |
|
| 23 | ZCMUB014 | O-RING - KICK SHAFT & OIL FILL PLUG | $ 1.42 |
|
| 24 | ECMU0280 | GUARD - COUNTERSHAFT SPROCKET - CX50 VENOM | $ 33.25 |
|
| 25 | HCBC0412 | M4 x 0.7 x 12 - SHCS - ZINC | $ 1.09 |
|
| 26 | HCNL0401 | 4MM LOCK NUT | $ 1.09 |
|
| 27 | ECC60028 | BUSHING - ENGINE PIVOT - 12MM | $ 13.22 |
|
| 28 | HCWF0401 | 4MM FLAT WASHER | $ 0.53 |
|
| ENGINE | EACS2020FWE | ENGINE - 2020 FACTORY WORKS EDITION | $ 2379.88 |
|
| KIT | ZKMU2016 | GASKET KIT - COMPLETE - 50CC VENOM | $ 65.52 |
|
